Features:
Geometry:
| SIZE | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Reach | 376 | 397 | 419 | 434.5 | 444 |
| Stack | 553 | 567 | 576 | 590 | 609 |
| Head Tube Angle | 70.0° | 71.0° | 71.0° | 71.0° | 71.0° |
| Head Tube Length | 110 | 120 | 130 | 145 | 165 |
| Seat Tube Length | 335.6 | 406.4 | 457.2 | 508 | 558.8 |
| BB Drop | 60 | 60 | 60 | 60 | 60 |
| Wheelbase | 1032 | 1047.5 | 1073 | 1093 | 1109 |
| Chainstay Length | 435 | 435 | 435 | 435 | 435 |
| Top Tube Length, Actual | 534 | 547.5 | 570 | 591.5 | 610.3 |
| Top Tube Length, Effective | 545 | 570 | 595 | 615 | 630 |
| Seat Tube Angle | 73.0° | 73.0° | 73.0° | 73.0° | 73.0° |
| Standover Height | 709 | 750.5 | 780 | 812 | 845.5 |
| Stem Length | 80 | 80 | 90 | 90 | 100 |
| Stem Angle | 6° | 6° | 6° | 6° | 6° |
| Crank Length | 170 | 170 | 175 | 175 | 175 |
| Fork Length | 420 | 420 | 420 | 420 | 420 |
| Fork Rake | 43 | 43 | 43 | 43 | 43 |
| Frame: | Surly Bridge Club, Seatpost Clamp: Surly Stainless 30.0 |
| Fork: | Surly Bridge Club |
| Headset: | Cane Creek 40 |
| Wheels: | WTB ST i21 TCS Front Hub: Novatec 9x100 QR Rear Hub: Novatec 9x141 QR 11-spd |
| Tyres: | Surly Extraterrestrial 700x41, 60tpi Tubeless Ready |
| Brakes: | Tektro HD-M275 hydraulic disc, Rotors: Tektro 160/160mm |
| Shifters: | Shimano Deore M5100 Rapid Fire |
| Derailleurs: | Rear: Shimano Deore M5100 Shadow Plus |
| Crankset: | Shimano Deore M5100 32t |
| Cassette: | Shimano Deore CSM5100 11-51t, Chain: KMC X11 EPT |
| Bottom bracket: | Shimano BSA |
| Pedals: | |
| Handlebar: | Surly Terminal Bar: XS,S - 718mm / M,L,XL - 735m |
| Stem: | Promax, 31.8mm |
| Seatpost: | Promax, 27.2mm |
| Saddle: | WTB Volt 142 |
| Accessories: | grip: Velo Black |
