The Katu is one of our favorite options for a nimble electric city bike.
Small 20" wheels makes the bike compact and manouverable. The bike comes with a great spec list of Bosch mid drive motor, Shimano 8 speed internal hub, Shimano Hydraulic Disc brakes, and integrated lights.
It also comes with a fantastic frame mounted front basket, double leg kickstand. It doesnt take up much space, so great for apartments or smaller living space.
It makes a great bike for commuting, carying shopping or even maybe a dog in the front and is compatible with a range of frame mounted rear child seats.
Geometry
| SIZE | U |
|---|---|
| 1 - SEAT TUBE (C-T) | 468 (Bafan 458) |
| 2 - TOP TUBE (EFF) | 575 |
| 3 - HEAD TUBE | 250 |
| 4 - CHAINSTAY | 440 |
| 5 - BB HEIGHT | 268 |
| 6 - BB DROP | 18 |
| 7 - WHEELBASE | 1096 |
| 8 - HEAD ANGLE | 67.7º |
| 9 - SEAT ANGLE | 70.3º |
| 10 - STANDOVER | 655 |
| 11 - REACH | 401 |
| 12 - STACK | 531 |
| 13 - FORK LENGTH | 355 |
| RAKE | 28 |
| Frame: | |
| Fork: | |
| Wheels: | 20" |
| Tyres: | Kenda 841 20x2.25 Reflex |
| Brakes: | Shimano MT200 Hydraulic Disc |
| Shifters: | Shimano SL-C6000 Nexus 8-Speed |
| Derailleurs: | Nexus 8-Speed |
| Crankset: | |
| Cassette: | |
| Bottom bracket: | |
| Pedals: | |
| Handlebar: | |
| Stem: | |
| Seatpost: | |
| Saddle: | |
| Motor: | BOSCH Active 25 kmh |
| Battery: | BOSCH Performance 400Wh |
| Display: | BOSCH Performance Purion |
| Lights: | Joss Spanninga Kendo 15 lux/Spanninga Pixeo |
| Accessories: | Ursus Big Foot double central alloy |
