Made to cross countries and continents via all kinds of roads and tracks, this bike is a versatile, fast-rolling adventure bike with a front rack and multiple luggage mounts. A dynamo lighting system will help keep you safe and seen where ever you ride.
{{ 'Leave your e-mail address so we can send you an e-mail when this product is back in stock.' | t }}
The Beyond 2 sports an impressive build kit with a front rack and dynamo light set up designed to keep you on the road for longer. Flared handlebars make long days comfortable and tan side wall tyres complete the look.
Features:
- Size XS and S will come with 27.5’’ wheels to ensure proper fit without any compromises in geometry.
- Double butted crmo frame with tapered head tube, rack and fender mounts, BSA bottom bracket and rear light cable routing.
- Fork with internal light cable routing and fender, rack and triple cage mounts.
- Toptube bag direct mounts, triple cage mounts on downtube for optimized bottle position and bottle cage mounts underneath the downtube.
- Sram Apex 1 x 11 groupset with wide range gearing and TRP Spyre brakes with Jagwire KEB-SL compressionless cable housing.
- Bombtrack Ames forged aluminium crank with narrow wide chainring.
- Wide, tubeless ready WTB ST i23 rims with tubeless ready Panaracer Gravelking SK 2.0’’ tires.
- Hub dynamo with Supernova E3 Pure 3 head lamp and E3 tail light.
- Bombtrack Tau 12 mm rear through axle hub.
- Bombtrack Deck front rack
Geometry
| Bike Size | XS | S | M | L | XL |
| Wheel size | 27.5'' | 27.5'' | 29'' | 29'' | 29'' |
| Seat Tube Length | 400 | 440 | 480 | 520 | 560 |
| Horizontal TT length | 494 | 522 | 558 | 590 | 623 |
| Seat Angle | 75.0° | 74.5° | 73.5° | 73.0° | 72.5° |
| Head Angle | 70.0° | 70.5° | 71.0° | 72.0° | 72.0° |
| Headtube Length | 100 | 130 | 150 | 190 | 220 |
| BB Drop | 55 | 55 | 70 | 70 | 70 |
| Chainstay Length | 425 | 425 | 455 | 455 | 455 |
| Fork Offset | 50 | 50 | 50 | 50 | 50 |
| Trail | 73 | 70 | 73 | 67 | 67 |
| Wheelbase Length | 1000 | 1021 | 1065 | 1082 | 1109 |
| Standover | 727 | 761 | 802 | 842 | 873 |
| Reach | 349 | 364 | 379 | 392 | 411 |
| Stack | 538 | 568 | 604 | 646 | 675 |
| Front Center | 581 | 602 | 620 | 636 | 663 |
| Axle to Crown | 420 | 420 | 420 | 420 | 420 |
| Minimum rider height * | 1500 | 1600 | 1700 | 1790 | 1880 |
| Maximum rider height * | 1610 | 1710 | 1810 | 1900 | 1990 |
| Frame | 4130 double butted crmo, TA, rack / fender mounts, internal light cable routing, 73 mm BSA BB shell |
| Fork | 4130 crmo, double butted blades, TA, 1.1/2'' - 1.1/8'', fender / rack / triple cage mounts, internal hub dynamo cable routing |
| Wheels | KT dynamo hub, 6-bolt disc 15x100mm, Rear Hub: BOMBTRACK TAU sealed hub,11-speed, 6-bolt disc. Rims: WTB ST i23 double wall, TCS 2.0, 32h |
| Tyres | PANARACER GRAVELKING SK XS - S 48-584 /M - XL 50-622, tubeless ready |
| Brakes | TRP SPYRE C mechanic disc brakes with 180 mm F / 160 mm R rotors |
| Shifters | SRAM Apex double tap 1 x 11 |
| Derailleurs | SRAM APEX 1, clutch, long cage |
| Crankset | BOMBTRACK AMES forged aluminium crank, 24 mm spindle |
| Cassette | SRAM PG-1130 11-speed, 11 - 42 T |
| Bottom bracket | BSA sealed BB, external cups |
| Pedals | - |
| Handlebar | BOMBTRACK BEYOND travel bar, 31.8 mm, 30° flare |
| Stem | BOMBTRACK WANDER forged aluminium stem, +17° |
| Seatpost | BOMBTRACK BEECH 27.2 mm x 400 mm |
| Saddle | BOMBTRACK ORIGIN saddle |
| Accessories | BOMBTRACK DECK frontrack, aluminium, SUPERNOVA E3 PURE 3 front, E3 TAIL LIGHT 2 rear |
